SCK 35-300mm² 7.5-22.4mm Electrical Equipment Outlet Connection Clamp C-Type Temperature Measuring Clamp
C-type equipment clamps are made of special aluminum alloy with good electrical conductivity, and the structure is composed of reasonable C-type and hinged wedges. When the hinged wedges are under the action of external force, the wires are pressed between the clamp shell and the wedge between. When the wire is thermally expanded and contracted, the C-type structure should have good elasticity and always maintain a lasting and constant contact pressure between the wire clip and the wire. It changes with the external environment and load conditions, and the contact pressure remains unchanged, which meets the requirements of continuous connection.
C-type equipment clamps are used to connect the outgoing terminals of power supply electrical equipment (such as isolating switches, circuit breakers, transformers, wall bushings, drop-out fuses; grounding wires, etc.) The product is divided into single-wire outlet and double-wire outlet, which are suitable for the installation of wires of various types and specifications.
Product Description
Product features
Advantages of C-type equipment clamps:
1. Contact performance: The contact surface between the wire clamp and the electrical equipment and the wire is large, the clamping force is constant, the DC resistance ratio is between 0.85 and 0.9, the connection between the equipment and the wire is safer and more reliable, and the long-term connection is 0 fault, repair;
2. Installation indicators: copper-magnesium-aluminum alloy material, stainless steel bolts are fastened, no installation tools are required, only a conventional wrench can be installed, and it can fall off, suitable for high-altitude operations;
3. Connection performance: Made of special copper-magnesium-aluminum alloy, no electromagnetic loss, corrosion, oxidation, suitable for the connection of copper-aluminum transition wires and busbars, fewer types of equipment clips, suitable for a wide range of wires of various specifications.
Structural features of C-type equipment clamps:
1. Non-magnetic material, no power loss
2. Wedge elastic clamping, reliable connection
3. Easy to install and disassemble
4. Applicable to various wire combinations, with strong suitability
5. Reusable and long life
Product details
Products real shot
A corner of the production workshop
Product packaging
Product application case
